Product Name | Push Button Station |
Button Color | Red, Green, Yellow |
Contact Type | Contact Type SPST |
Thermal Current (Ith) | 10A |
Insulation Voltage (Ui) | 600V |
Rated Voltage (V) | 240V |
Rated Current (A) | 3A |
Switch Contact | COM/NO/NC |
Operating Temperature | -25°C ~ +55°C |
Life Mechanical | 2,000,000 times |
Material: | ABS |
Push Button Dimension |
25mm/1 |
Overall Size | 135 x 68 x 54 mm |
Net Weight | 244g |
